At Pinnacle Concrete we offer High Density Polyurethane Foam Injection for concrete leveling, stabilization, and void filling applications. Foam injection offers similar great results as our grout-based method. With a range of installation methods and product performance characteristics, our foam method may be the best and most cost-effective solution for your leveling needs.

The Foam Injection Concrete Leveling Process

Foam injection concrete leveling uses a polyurethane material. It is injected under the slab as a liquid and expands before curing, filling any voids and raising the concrete. In only seconds it will reach its final volume. After curing, it will never lose its density and will maintain its compressive strength. Our foam leveling material won’t break down or wash out from water.

Foam injection concrete leveling can be done quickly, with the surface being usable immediately. Injection hole sizes (5/8-inch, or about the size of a dime) are smaller than our stone slurry grout leveling holes, potentially making it a good solution for highly visible areas or decorative concrete surfaces.

Best Uses for Foam Injection Concrete Leveling

There are many times when foam injection is the best repair process to address a problem. These include:

  • Areas Where Cleanliness is Important – Due to the ability to use fewer and smaller holes, minimal dust is created in preparing the surface. Additionally, because there is a mechanical connection between the injection equipment and the slab, minimal material is exposed to the surface or surroundings.
  • Sensitive or Expensive Surfaces – Because foam injection uses small (3/8”) holes, it is an ideal repair method for settled slabs which have decorative coatings, surface treatments or other characteristics, such as brick and stone overlays. Injection holes can be patched with stained concrete to blend in with the surrounding material. For repairing slab floors covered with wood, we cut a small access area to reveal the concrete floor, and then secure the wood back into place after leveling is completed. For carpeted areas, small squares can be cut to reveal the concrete surface, and then be glued back down after leveling.
  • Hard to Reach Work Sites – Foam injection equipment can be transported to work sites that are inaccessible to grout trucks, making it an effective solution to virtually any job location.

Cautions When Considering Foam Injection Concrete Leveling

Overall, foam injection concrete leveling will give you a satisfactory result, however, for many applications it is inferior to our stone slurry grout concrete leveling solution. It doesn’t have the ability to fully fill voids as well as stone slurry grout can. And, although our technicians are highly trained in both methods, foam injection concrete leveling can be harder to control, as its lifting capabilities are based on expanding foam, rather than the consistent filling of the void with our grout solution. Also, foam is almost always more expensive.

CONCRETE LIFTING NEAR ME

Pinnacle Concrete Solutions (Concrete Lifting Near Me) are your local experts for all your lifting, leveling and concrete repair needs in Connecticut and surrounding states. Concrete slabs that are cracked, sunken or uneven can be both dangerous and a liability on your property. If you’re looking to avoid safety hazards and restore the curb appeal of your sidewalk, driveway, pool deck, parking lot or any other concrete surface, the experienced technicians at Pinnacle Concrete Solutions can help.

As your regional Foam concrete lifting company, we have the experience, expertise and equipment to level your sunken concrete and return it back to a safe, stable position. Don’t hesitate to call us or contact us online to schedule an on-site inspection your free cost estimate in Connecticut or an area nearby.
